विशेषताएं:
अनुप्रयोगों:
विद्युत पैरामीटर
| मूल्यांकित किया गया निवेश | 0.5 एक-6000A |
| माप सीमा | 10% -130% में |
| मूल्यांकित उत्पादन | 0.333 वी (एसी) या 0-5 ए |
| अनुपात | ± ± 0.1% |
| अवस्था कोण | Min min 5min |
| इन्सुलेशन प्रतिरोध | DC500V / 100MΩmin |
मैकेनिकल पैरामीटर
| मामला | पीसी / UL94-V0 |
| अटेरन | पीसी |
| कोर | सिलिकॉन |
| आंतरिक ढांचा | epoxy |
| निर्माण | टाई |
| संचालन तापमान | -25 ℃ ~ + 75 ℃ |
| वर्तमान आर्द्रता | ≤85% |
| आउटपुट कनेक्शन | टर्मिनल या UL1015 22AWG वायर 1.5 मी |
चयन का प्रकार
पी / एन | मूल्यांकित किया गया निवेश (ए) | उत्पादन (ए) | शुद्धता | आयाम (मिमी) | |||||||||
| ए | बी | सी | डी | ए | एफ | जी | एच | मैं | |||||
SCTK731Y (33) | 100-400A | 1 ए / 5A | 0.2,0.5,1.0 | 32 | 32 | 43 | 96 | 96 | 32 | 32 | 50 | 32 | |
SCTK731Y (34) | 100-600A | 1 ए / 5A | 0.2,0.5,1.0 | 32 | 42 | 43 | 96 | 106 | 32 | 32 | 50 | 32 | |
SCTK731Y (35) | 100-1000A | 1 ए / 5A | 0.2,0.5,1.0 | 32 | 52 | 43 | 96 | 116 | 32 | 32 | 50 | 32 | |
SCTK731Y (36) | 100-1200A | 1 ए / 5A | 0.2,0.5,1.0 | 32 | 62 | 43 | 96 | 126 | 32 | 32 | 50 | 32 | |
SCTK731Y (38) | 200-1500A | 1 ए / 5A | 0.2,0.5,1.0 | 32 | 82 | 43 | 96 | 146 | 32 | 32 | 50 | 32 | |
SCTK731Y (310) | 250-2000A | 1 ए / 5A | 0.2,0.5,1.0 | 32 | 102 | 43 | 96 | 166 | 32 | 32 | 50 | 32 | |
SCTK731Y (312) | 500-2500A | 1 ए / 5A | 0.2,0.5,1.0 | 32 | 122 | 43 | 96 | 186 | 32 | 32 | 50 | 32 | |
SCTK731Y (313) | 500-3000A | 1 ए / 5A | 0.2,0.5,1.0 | 32 | 132 | 43 | 96 | 196 | 32 | 32 | 50 | 32 | |
SCTK731Y (44) | 100-600A | 1 ए / 5A | 0.2,0.5,1.0 | 42 | 42 | 53 | 106 | 106 | 32 | 32 | 50 | 32 | |
SCTK731Y (45) | 100-1000A | 1 ए / 5A | 0.2,0.5,1.0 | 42 | 52 | 53 | 106 | 116 | 32 | 32 | 50 | 32 | |
SCTK731Y (46) | 100-1200A | 1 ए / 5A | 0.2,0.5,1.0 | 42 | 62 | 53 | 106 | 126 | 32 | 32 | 50 | 32 | |
SCTK731Y (48) | 200-1500A | 1 ए / 5A | 0.2,0.5,1.0 | 42 | 82 | 53 | 106 | 146 | 32 | 32 | 50 | 32 | |
SCTK731Y (410) | 250-2000A | 1 ए / 5A | 0.2,0.5,1.0 | 42 | 102 | 53 | 106 | 166 | 32 | 32 | 50 | 32 | |
SCTK731Y (412) | 500-2500A | 1 ए / 5A | 0.2,0.5,1.0 | 42 | 122 | 53 | 106 | 186 | 32 | 32 | 50 | 32 | |
SCTK731Y (413) | 500-3000A | 1 ए / 5A | 0.2,0.5,1.0 | 42 | 132 | 53 | 106 | 196 | 32 | 32 | 50 | 32 | |
SCTK731Y (55) | 100-1000A | 1 ए / 5A | 0.2,0.5,1.0 | 52 | 52 | 63 | 116 | 116 | 32 | 32 | 50 | 32 | |
SCTK731Y (56) | 100-1200A | 1 ए / 5A | 0.2,0.5,1.0 | 52 | 62 | 63 | 116 | 126 | 32 | 32 | 50 | 32 | |
SCTK731Y (58) | 200-1500A | 1 ए / 5A | 0.2,0.5,1.0 | 52 | 82 | 63 | 116 | 146 | 32 | 32 | 50 | 32 | |
SCTK731Y (510) | 250-2000A | 1 ए / 5A | 0.2,0.5,1.0 | 52 | 102 | 63 | 116 | 166 | 32 | 32 | 50 | 32 | |
SCTK731Y (512) | 500-2500A | 1 ए / 5A | 0.2,0.5,1.0 | 52 | 122 | 63 | 116 | 186 | 32 | 32 | 50 | 32 | |
SCTK731Y (513) | 500-3000A | 1 ए / 5A | 0.2,0.5,1.0 | 52 | 132 | 63 | 116 | 196 | 32 | 32 | 50 | 32 | |
SCTK731Y (516) | 1000-5000A | 1 ए / 5A | 0.2,0.5,1.0 | 52 | 162 | 63 | 116 | 226 | 32 | 32 | 50 | 32 | |
SCTK731Y (66) | 100-1200A | 1 ए / 5A | 0.2,0.5,1.0 | 62 | 62 | 73 | 126 | 126 | 32 | 32 | 50 | 32 | |
SCTK731Y (68) | 200-1500A | 1 ए / 5A | 0.2,0.5,1.0 | 62 | 82 | 73 | 126 | 146 | 32 | 32 | 50 | 32 | |
SCTK731Y (610) | 250-2000A | 1 ए / 5A | 0.2,0.5,1.0 | 62 | 102 | 73 | 126 | 166 | 32 | 32 | 50 | 32 | |
SCTK731Y (612) | 500-2500A | 1 ए / 5A | 0.2,0.5,1.0 | 62 | 122 | 73 | 126 | 186 | 32 | 32 | 50 | 32 | |
SCTK731Y (613) | 500-3000A | 1 ए / 5A | 0.2,0.5,1.0 | 62 | 132 | 73 | 126 | 196 | 32 | 32 | 50 | 32 | |
SCTK731Y (616) | 1000-5000A | 1 ए / 5A | 0.2,0.5,1.0 | 62 | 162 | 73 | 126 | 226 | 32 | 32 | 50 | 32 | |
SCTK731Y (88) | 200-1500A | 1 ए / 5A | 0.2,0.5,1.0 | 82 | 82 | 93 | 146 | 146 | 32 | 32 | 50 | 32 | |
SCTK731Y (810) | 250-2000A | 1 ए / 5A | 0.2,0.5,1.0 | 82 | 102 | 93 | 146 | 166 | 32 | 32 | 50 | 32 | |
SCTK731Y (812) | 500-2500A | 1 ए / 5A | 0.2,0.5,1.0 | 82 | 122 | 93 | 146 | 186 | 32 | 32 | 50 | 32 | |
SCTK731Y (813) | 500-3000A | 1 ए / 5A | 0.2,0.5,1.0 | 82 | 132 | 93 | 146 | 196 | 32 | 32 | 50 | 32 | |
SCTK731Y (814) | 800-4000A | 1 ए / 5A | 0.2,0.5,1.0 | 82 | 142 | 93 | 146 | 206 | 32 | 32 | 50 | 32 | |
SCTK731Y (816) | 1000-5000A | 1 ए / 5A | 0.2,0.5,1.0 | 82 | 162 | 93 | 146 | 226 | 32 | 32 | 50 | 32 | |
SCTK731Y (1010) | 250-4000A | 1 ए / 5A | 0.2,0.5,1.0 | 102 | 102 | 113 | 166 | 166 | 32 | 32 | 50 | 32 | |
SCTK731Y (1111) | 250-4000A | 1 ए / 5A | 0.2,0.5,1.0 | 112 | 112 | 123 | 176 | 176 | 32 | 32 | 50 | 32 | |
SCTK731Y (1212) | 500-4000A | 1 ए / 5A | 0.2,0.5,1.0 | 122 | 122 | 133 | 186 | 186 | 32 | 32 | 50 | 32 | |
SCTK731Y (1313) | 500-5000A | 1 ए / 5A | 0.2,0.5,1.0 | 132 | 132 | 143 | 196 | 196 | 32 | 32 | 50 | 32 | |
SCTK731Y (1515) | 600-5000A | 1 ए / 5A | 0.2,0.5,1.0 | 152 | 152 | 163 | 216 | 216 | 32 | 32 | 50 | 32 | |
SCTK731Y (1616) | 800-5000A | 1 ए / 5A | 0.2,0.5,1.0 | 162 | 162 | 173 | 226 | 226 | 32 | 32 | 50 | 32 | |
SCTK731Y (1818) | 1000-5000A | 1 ए / 5A | 0.2,0.5,1.0 | 182 | 182 | 193 | 246 | 246 | 32 | 32 | 50 | 32 | |
SCTK731Y (2020) | 1000-6000A | 1 ए / 5A | 0.2,0.5,1.0 | 202 | 202 | 213 | 266 | 266 | 32 | 32 | 32 | 50 | |
नोट: उत्पाद विनिर्देशों को अनुकूलित किया जा सकता है
